Allen & Heath Avantis Solo 64-Channel / 42-Bus Digital Mixer with Touchscreen

Add to wishlist
SKU: N/A
Add to wishlist

$619.00

Compare

Description

Allen & Heath AVANTIS-SOLO Specs

Key Specs
Max I/O Capacity
64x Input / 42x Output
Number of Analog Input Channels
6
Number of Mic Preamps
6
Number of Analog Output Channels
6
Faders & Level Adjustment
12x 3.9″ / 100 mm Fader
Built-In Effects
Reverb
Delay
Chorus
Flanger
Phaser
Analog Inputs
6x XLR Balanced Mic/Line Input
Analog Outputs
6x XLR Balanced Line Output
1x 1/4″ TRS Stereo Headphone Output
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
Digital I/O
2x RJ45 AES3 (Network)
1x XLR AES3 Input
1x XLR AES3 Output
1x etherCON (I/O)
USB I/O
1x USB-A 2.0 (2-Track Record, Audio Playback, External Memory)
1x USB-A 3.0 / 3.1/3.2 Gen 1 (2-Track Record, Audio Playback, External Memory)
Wireless
No
Rack Mountable
No
Mixer
Max I/O Capacity
64x Input / 42x Output
Number of Analog Input Channels
6
Number of Mic Preamps
6
Number of Analog Output Channels
6
Mix Routing
12x Stereo FX Return
Groups
8x Mute Group
16x DCA Group
Presets
No
Display
15.6″ Touchscreen
Faders & Level Adjustment
12x 3.9″ / 100 mm Fader
Meters
Main Meter:
2x 24-Segment LED
Signal Processing
Gain/Trim Range
Line/Mic:
+5 dB to ±60 dB (in 1 dB Steps)
Input Pad
-20 dB
Input Polarity
Normal/Reverse
Dynamic Processing
Input Channels:
Compressor, Gate
Master:
Compressor, Limiter
Graphic EQ
28-Band 1/3 Octave, ±12 dB 31 Hz to 16 kHz
Filters
High-Pass: 20 Hz to 2 kHz, 12 dB/Octave
Low-Pass: 20 Hz to 20 kHz, 12 dB/Octave
Solo/Mute
Mute, PFL per Input Channel, Bus, Master
Built-In Effects
Reverb
Delay
Chorus
Flanger
Phaser
Audio Delay
Adjustable Up to 680 ms
Automatic Mic Mixing
Yes
Digital Audio
Sample Rates
AD/DA Conversion:
96 kHz
AES3 Output:
44.1 / 48 / 96 kHz
Stereo Playback:
44.1 / 48 / 96 kHz
Stereo Record:
96 kHz
Bit Depth
AD/DA Conversion:
Up to 24-Bit
Word Clock Input
44.1 to 96 kHz
Performance
Frequency Response
20 Hz to 30 kHz +0/-0.8 dB
Max Input Level
Mic/Line Input:
+30 dBu
Analog Dynamic Range
109 dB
I/O Impedance
XLR Input:
> 4 Kilohms (Pad Out)
> 10 Kilohms (Pad In)
AES3 Input:
110 Ohms
Line Output:
< 75 Ohms
AES3 Output:
110 Kilohms
SNR
-92 dB
THD+N
0.0015% (at +16 dBu Output, 1 kHz 0 dB Gain)
Signal Generator
Sine, White, Pink, or Band-Pass Noise (Assignable to Any Mix)
Connectivity
Analog Inputs
6x XLR Balanced Mic/Line Input
Analog Outputs
6x XLR Balanced Line Output
1x 1/4″ TRS Stereo Headphone Output
1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
Phantom Power
+48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital I/O
2x RJ45 AES3 (Network)
1x XLR AES3 Input
1x XLR AES3 Output
1x etherCON (I/O)
MIDI I/O
No
USB I/O
1x USB-A 2.0 (2-Track Record, Audio Playback, External Memory)
1x USB-A 3.0 / 3.1/3.2 Gen 1 (2-Track Record, Audio Playback, External Memory)
Expansion Ports
2x I/O Card
Wireless
No
External Display I/O
No
Recording
Max Multitrack Recording
16 Tracks
Media Support
USB Drive
File Format Support
WAV
Compatibility
OS Compatibility
Computer: macOS / Windows
Mobile: Android/iOS
Power
Input Power
100 to 240 VAC, 50 / 60 Hz
Physical
Rack Mountable
No
Operating Conditions
32 to 104°F / 0 to 40°C
Dimensions
32.6 x 28.7 x 16.7″ / 828 x 729 x 424.2 mm
Weight
53.6 lb / 24.3 kg
Packaging Info
Package Weight
55 lb
Box Dimensions (LxWxH)
32.5 x 28.5 x 16.25″
